The F050 is a straight forward pressure indicator with large 26mm (1") high digits. The measuring unit to be displayed below the pressure is simply selected through an alphanumeric configuration menu. No adhesive labels have to be put on the outside of the enclosure: a weather proof and user-friendly solution!
The configuration of the Span, off-set and number of decimals is done through software functions, without any sensitive DIP-switches or trimmers.

Features

• Displays actual pressure and measuring unit.
• Very large 26mm (1") high digits for pressure.
• Selectable on-screen engineering units: mBar - Bar - PSI.
• Number of digits for pressure: 5½.
• Piegraph indication: ten segments.
• Green or amber LED backlight with adjustable intensity.
• Auto backup of settings in EEPROM memory.
• Easy configuration with clear alphanumerical display.
• Operational temperature: -40°C to +80°C (-40°F to 176°F).

Applications

• The F-Series is your first and best choice for field mount indicators. Especially in harsh weather conditions like rain, snow, salty atmospheres and temperatures between -40°C up to +80°C (-40°F up to 176°F) for safe and hazardous area applications!

Applications where a basic pressure measurement display is required without pressure monitoring or signal re-transmission.

• Robust IP66, IP67 (NEMA4X) field enclosure. It is so rugged, you can even stand on it!
• Intrinsically Safe available - ATEX, IECEx, FM and CSA approval for gas and dust applications.
• Programming can be done by your own crew, with the sensible menu-driven structure, saving cost and irritation. Know one, know them all!
• Very diverse mounting possibilities: walls, pipes, panels or directly onto outdoor sensors.

The D050 is a straight forward, panel mount pressure indicator. The measuring unit to be displayed is simply selected through an alfa-numerical configuration menu. No adhesive labels have to be put on the outside of the enclosure: a weather proof and user friendly solution! The configuration of the Span, off-set and number of decimals is done through software functions, without any sensitive dip-switches or trimmers.

Features

• Displays actual pressure and measuring unit.
• Very large 26mm (1") digits.
• Piegraph indication: ten segments.
• Number of digits for pressure: 5½.
• Selectable on-screen engineering units:
  mBar - Bar - PSI.
• Auto backup of all settings.
• Operational temperature: -40°C to +80°C (-40°F to 176°F).
• LED backlight option.
• Aluminum DIN front panel of 144 x 72mm (5.67" x 2.83") according DIN 43700 / IEC 61554.

Applications

• The D-Series is a DIN-sized display and the better alternative for your existing, not waterproof, front panel mount indicators in extreme weather outdoor applications or e.g. in food industries where working environments are often cleaned with powerful water jets.
• The D050 fits in applications where a basic pressure measurement display is required without pressure monitoring.

• Unique, robust IP66, IP67 (NEMA4X) panel mount front enclosure made of die cast aluminum, allowing even big jets of water and total immersion.
• Programming can be done by your own crew with the exact same, plain and sensible menu-driven structure like the F-Series, saving cost and irritation. Know one, know them all!

The F151 incorporates two completely separated pressure indicators in one enclosure. There is no relationship between the inputs, even different measuring units can be used.
The measuring unit is displayed together with the input channel information A or B. The F151 can be set to show the selected information manually or with an automatic toggle function.

Features

• Two completely separated pressure indicators in one enclosure.
• Displays actual pressure, measuring unit and product I.D. simultaneously.
• Pressure: six 17mm (0.67") digits.
• Separately selectable engineering units for each pressure input: mBar - Bar - PSI or no unit
• Green LED backlight.
• Backup of settings in EEPROM memory.
• Operational temperature: -40°C to +80°C (-40°F to 176°F).

Applications

• The F-Series is your first and best choice for field mount indicators. Especially in harsh weather conditions like rain, snow, salty atmospheres and temperatures between -40°C up to +80°C (-40°F up to 176°F) for safe and hazardous area applications!

For those applications where two indicators are required but one single and compact enclosure is desired.

• Robust IP66, IP67 (NEMA4X) field enclosure. It is so rugged, you can even stand on it!
• Intrinsically Safe available - ATEX, IECEx, FM and CSA approval for gas and dust applications.
• Programming can be done by your own crew, with the sensible menu-driven structure, saving cost and irritation. Know one, know them all!
• Very diverse mounting possibilities: walls, pipes, panels or directly onto outdoor sensors.

The F053 is a versatile pressure indicator with continuous pressure monitoring feature. It offers the ability to set one low pressure and one high pressure alarm value. If desired, an ignore function can be set up to allow for an incorrect pressure for a certain period of time. The configuration of the Span, off-set and number of decimals is done through software functions, without any sensitive DIP-switches or trimmers. The display shows the actual pressure, alarm values, alarm messages and status.
On-screen engineering units are easily configured from a comprehensive selection.

Features

• Pressure monitoring: two alarm values can be set: low and high pressure alarm.
• Alarm values can be changed by the operator or they can be passcode protected.
• One alarm output for high, low or both combined pressure alarms.
• Pressure: six large 17mm (0.67") digits.
• Selectable on-screen engineering units: mBar - Bar - PSI.
• Red flashing LED backlight in case of a pressure alarm; intensity adjustable.
• Displays clear alarm messages.
• Auto backup of settings in EEPROM memory.
• Easy configuration with clear alphanumerical display.
• Operational temperature: -40°C to +80°C (-40°F to 176°F).

Applications

• The F-Series is your first and best choice for field mount indicators. Especially in harsh weather conditions like rain, snow, salty atmospheres and temperatures between -40°C up to +80°C (-40°F up to 176°F) for safe and hazardous area applications!
• For applications where continuous pressure measurement and monitoring is important without signal re-transmission.

• Robust IP66, IP67 (NEMA4X) field enclosure. It is so rugged, you can even stand on it!
• Intrinsically Safe available - ATEX, IECEx, FM and CSA approval for gas and dust applications.
• Programming can be done by your own crew, with the sensible menu-driven structure, saving cost and irritation. Know one, know them all!
• Very diverse mounting possibilities: walls, pipes, panels or directly onto outdoor sensors.

The F153 is a versatile pressure indicator featuring continuous pressure monitoring. It offers the ability to set two low and two high pressure alarm values. If desired, an ignore function can be set up to allow for an incorrect temperature for a certain period of time. Up to five outputs are available to transmit alarm conditions and actual pressure.
The display shows the actual pressure, alarm values, alarm messages and status. On-screen engineering units are easily configured from a comprehensive selection.

Features

• Pressure monitoring: four alarm values can be set: low-low, low, high and high-high pressure alarm.
• Alarm values can be changed by the operator or they can be passcode protected.
• Analog output to transmit the actual pressure.
• Pressure and alarm values: six large 17mm (0.67") digits.
• Displays pressure, measuring unit and alarm messages simultaneously.
• Alarm ignore function allows an incorrect pressure for a certain period of time.
• Selectable on-screen engineering units: mBar - Bar - PSI or no unit
• Green LED backlight.
• Backup of settings in EEPROM memory.
• Operational temperature: -40°C to +80°C (-40°F to 176°F).

Applications

• The F-Series is your first and best choice for field mount indicators. Especially in harsh weather conditions like rain, snow, salty atmospheres and temperatures between -40°C up to +80°C (-40°F up to 176°F) for safe and hazardous area applications!

For applications where continuous pressure measurement and monitoring is important. Also signal re-transmission of the actual pressure or serial communication is required.

• Robust IP66, IP67 (NEMA4X) field enclosure. It is so rugged, you can even stand on it!
• Intrinsically Safe available - ATEX, IECEx, FM and CSA approval for gas and dust applications.
• Programming can be done by your own crew, with the sensible menu-driven structure, saving cost and irritation. Know one, know them all!
• Very diverse mounting possibilities: walls, pipes, panels or directly onto outdoor sensors.

The D053 is a versatile, panel mount pressure indicator with continuous pressure monitoring feature. It offers the facility to set one low pressure and one high pressure alarm value. If desired, an ignore function can be set up to allow for an incorrect pressure for a certain period of time.

Features

• Displays actual pressure and alarm values.
• Two alarm values can be entered: low and high pressure alarm.
• Pressure: six large 17mm (0.67) digits.
• Selectable on-screen engineering units:
  mBar - Bar - PSI.
• Operational temperature: -40°C to +80°C (-40°F to 176°F).
• Red flashing LED backlight in case of a pressure alarm.
• Aluminum DIN front panel of 144 x 72mm (5.67" x 2.83") according DIN 43700 / IEC 61554.

Applications

• The D-Series is a DIN-sized display and the better alternative for your existing, not waterproof, front panel mount indicators in extreme weather outdoor applications or e.g. in food industries where working environments are often cleaned with powerful water jets.
• The D053 fits in applications where continuous pressure measurement and monitoring is important.

• Unique, robust IP66, IP67 (NEMA4X) panel mount front enclosure made of die cast aluminum, allowing even big jets of water and total immersion.
• Programming can be done by your own crew with the exact same, plain and sensible menu-driven structure like the F-Series, saving cost and irritation. Know one, know them all!

The F143 is a versatile temperature indicator featuring continuous temperature monitoring. It offers the ability to set two low and two high temperature alarm values. If desired, an ignore function can be set up to allow for an incorrect temperature for a certain period of time. Up to five outputs are available to transmit alarm conditions and actual temperature.
The display shows the actual temperature, alarm values, alarm messages and status. On-screen engineering units are easily configured from a comprehensive selection.

Features

• Temperature monitoring: four alarm values can be set: low-low, low, high and high-high temperature alarm.
• Alarm values can be changed by the operator or they can be passcode protected.
• Analog output to transmit the actual temperature.
• Temperature and alarm values: six large 17mm (0.67") digits.
• Displays temperature, measuring unit and alarm messages simultaneously.
• Alarm ignore function allows an incorrect temperature for a certain period of time.
• Selectable on-screen engineering units: °C - °F - K or no unit
• Up to four configurable alarm outputs.
• Displays clear alarm messages.
• Green LED backlight.
• Backup of settings in EEPROM memory.
• Operational temperature: -40°C to +80°C (-40°F to 176°F).

Applications

• The F-Series is your first and best choice for field mount indicators. Especially in harsh weather conditions like rain, snow, salty atmospheres and temperatures between -40°C up to +80°C (-40°F up to 176°F) for safe and hazardous area applications!
• For applications where continuous temperature measurement and monitoring is important. Also signal re-transmission of the actual temperature or serial communication is required.
