The configuration of the Span, off-set and number of decimals is done through software functions, without any sensitive DIP-switches or trimmers.

• Displays level and height or percentage filled.
• Selectable on-screen engineering units for height: mm, cm, m, mtr, inch, ft, mmwk, mmwc, cmwk, cmwc, mwk, mwc, inwc, ftwc, mBar, Bar, PSI or no unit.
• Piegraph indication: ten segments.
• Auto backup of settings in EEPROM memory.
• Operational temperature: -40°C to +80°C (-40°F to 176°F).

Applications where a basic level measurement display is required without level monitoring, linearization or signal re-transmission.

The D070 is a straight forward, panel mount level indicator. The measuring unit to be displayed is simply selected through an alfa-numerical configuration menu. No adhesive labels have to be put on the outside of the enclosure: a weather proof and user friendly solution! The configuration of the Span, off-set and number of decimals is done through software functions, without any sensitive dip-switches or trimmers.

Features

• Displays flow rate and measuring units.
• Very large 26mm (1") digits.
• Piegraph indication: ten segments.
• Selectable on-screen engineering units; volumetric or mass.
• Ability to process all types of flowmeter signals.
• Auto backup of all settings.
• Operational temperature: -40°C to +80°C (-40°F to 176°F).
• LED backlight option.
• Aluminum DIN front panel of 144 x 72mm (5.67" x 2.83") according DIN 43700 / IEC 61554.

Applications

• The D-Series is a DIN-sized display and the better alternative for your existing, not waterproof, front panel mount indicators in extreme weather outdoor applications or e.g. in food industries where working environments are often cleaned with powerful water jets.

The D070 fits in applications where a basic level measurement display is required without level monitoring and linearization.

• Unique, robust IP66, IP67 (NEMA4X) panel mount front enclosure made of die cast aluminum, allowing even big jets of water and total immersion.
• Programming can be done by your own crew with the exact same, plain and sensible menu-driven structure like the F-Series, saving cost and irritation. Know one, know them all!

The F073 is a versatile level indicator with continuous level monitoring feature. It offers the ability to set one low level and one high level alarm value. If desired, an ignore function can be set up to allow for an incorrect level for a certain period of time. The configuration of the Span, off-set and number of decimals is done through software functions, without any sensitive DIP-switches or trimmers. The display shows the actual level, height or percentage, alarm values, alarm messages and status.
On-screen engineering units are easily configured from a comprehensive selection.

Features

• Displays level and height or percentage filled.
• Level monitoring: two alarm values can be set: low and high level alarm.
• Alarm values can be changed by the operator or they can be passcode protected.
• One alarm output for high, low or both combined level alarms.
• Level: six large 17mm (0.67") digits.
• Selectable on-screen engineering units for level: ml, L, m³, GAL, USGAL, kg, lb, bbl or no unit.
• Selectable on-screen engineering units for height: mm, cm, m, mtr, inch, ft, mmwk, mmwc, cmwk, cmwc, mwk, mwc, inwc, ftwc, mBar, Bar, PSI or no unit.
• Red flashing LED backlight in case of a level alarm; intensity adjustable.
• Displays clear alarm messages.
• Auto backup of settings in EEPROM memory.
• Easy configuration with clear alphanumerical display.
• Operational temperature: -40°C to +80°C (-40°F to 176°F).

Applications

• The F-Series is your first and best choice for field mount indicators. Especially in harsh weather conditions like rain, snow, salty atmosphers and temperatures between -40°C up to +80°C (-40°F up to 176°F) for safe and hazardous area applications!

Level measurement where continuous level monitoring is important without signal re-transmission.

• Robust IP66, IP67 (NEMA4X) field enclosure. It is so rugged, you can even stand on it!
• Intrinsically Safe available - ATEX, IECEx, FM and CSA approval for gas and dust applications.
• Programming can be done by your own crew, with the sensible menu-driven structure, saving cost and irritation. Know one, know them all!
• Very diverse mounting possibilities: walls, pipes, panels or directly onto outdoor sensors.

The F077 is a versatile level indicator with linearization and continuous level monitoring feature. In addition to the average Span, eight linearization points can be entered to compensate for the tank shape. The unit will interpolate between these points to increase the accuracy. With the level monitoring feature, one low level and one high level alarm value can be set. The configuration of the Span, off-set and number of decimals is done through software functions, without any sensitive DIP-switches or trimmers. The display shows the actual level, height or percentage, alarm values, alarm messages and status.

<p style="&quot;text-align:" justify;"="">On-screen engineering units are easily configured from a comprehensive selection.

• Very diverse mounting possibilities: walls, pipes, panels or directly onto outdoor sensors.

Level monitoring: two alarm values can be set: low and high level alarm.

•
• Displays clear alarm messages.
•   <p and="" area="" atmosphers="" best="" between="" c="" choice="" conditions="" especially="" f="" f-series="" field="" first="" for="" harsh="" hazardous="" in="" indicators.="" is="" li="" like="" mount="" safe="" salty="" style="" text-align:"="" temperatures="" the="" to="" up="" weather="" your=""> Level measurement where continuous level monitoring and linearization of the tank shape is important without signal re-transmission.

The F170 is a versatile level indicator featuring continuous level monitoring. It offers the ability to set two low and two high level alarm values. If desired, an ignore function can be set up to allow for an incorrect level for a certain period of time. Up to five outputs are available to transmit alarm conditions and actual level.
The display shows the actual level, height or percentage, alarm values, alarm messages and status. On-screen engineering units are easily configured from a comprehensive selection.

Features

• Level monitoring: four alarm values can be set: low-low, low, high and high-high level alarm.
• Alarm values can be changed by the operator or they can be passcode protected.
• Analog output to transmit the actual level.
• Level and alarm values: six large 17mm (0.67") digits.
• Displays level, height or percentage, measuring unit and alarm messages simultaneously.
• Alarm ignore function allows an incorrect level for a certain period of time.
• Selectable on-screen engineering units; volumetric or mass.
• Displays clear alarm messages.
• Green LED backlight.
• Backup of settings in EEPROM memory.
• Operational temperature: -40°C to +80°C (-40°F to 176°F).

Applications

• The F-Series is your first and best choice for field mount indicators. Especially in harsh weather conditions like rain, snow, salty atmosphers and temperatures between -40°C up to +80°C (-40°F up to 176°F) for safe and hazardous area applications!
• Level measurement and continuous level monitoring is desired as well as signal re-transmission of the level or serial communication.

• Robust IP66, IP67 (NEMA4X) field enclosure. It is so rugged, you can even stand on it!
• Intrinsically Safe available - ATEX, IECEx, FM and CSA approval for gas and dust applications.
• Programming can be done by your own crew, with the sensible menu-driven structure, saving cost and irritation. Know one, know them all!
• Very diverse mounting possibilities: walls, pipes, panels or directly onto outdoor sensors.

The F173 is a versatile level indicator featuring linearization and continuous level monitoring. In addition to the average Span, fifteen linearization points can be entered to compensate for the tank shape. The unit will interpolate between these points to increase accuracy. This linearization affects all displayed information as well as the alarm and analog outputs. With the level monitoring feature, two low and two high level alarm values can be set. If desired, an ignore function can be set up to allow for an incorrect level for a certain period of time. Up to five outputs are available to transmit alarm conditions and actual level.
The display shows the actual level, height or percentage, alarm values, alarm messages and status. On-screen engineering units are easily configured from a comprehensive selection.

• Fifteen point linearization of the tank shape - with interpolation.
• Level monitoring: four alarm values can be set: low-low, low, high and high-high level alarm.
• Alarm values can be changed by the operator or they can be passcode protected.
• Analog output to transmit the actual level.
• Level and alarm values: six large 17mm (0.67") digits.
• Displays level, height or percentage, measuring unit and alarm messages simultaneously.
• Alarm ignore function allows an incorrect level for a certain period of time.
• Selectable on-screen engineering units; volumetric or mass.
• Displays clear alarm messages.
• Green LED backlight.
• Backup of settings in EEPROM memory.
• Operational temperature: -40°C to +80°C (-40°F to 176°F).

Applications

• The F-Series is your first and best choice for field mount indicators. Especially in harsh weather conditions like rain, snow, salty atmosphers and temperatures between -40°C up to +80°C (-40°F up to 176°F) for safe and hazardous area applications!
• Level measurement where linearization of the tank shape and continuous level monitoring is important as well as signal re-transmission of the level or serial communication.

• Robust IP66, IP67 (NEMA4X) field enclosure. It is so rugged, you can even stand on it!
• Intrinsically Safe available - ATEX, IECEx, FM and CSA approval for gas and dust applications.
• Programming can be done by your own crew, with the sensible menu-driven structure, saving cost and irritation. Know one, know them all!
• Very diverse mounting possibilities: walls, pipes, panels or directly onto outdoor sensors.

The D073 is a versatile, panel mount level monitor with continuous level monitoring feature. It offers the facility to set one low level and one high level alarm value. If desired, an ignore function can be set up to allow for an incorrect level for a certain period of time.

Features

• Displays level, height and percentage filled.
• Two alarm values can be entered: low and high level alarm.
• Level: six large 17mm (0.67) digits.
• Selectable on-screen engineering units; volumetric or mass.
• Auto backup of all settings.
• Operational temperature: -40°C to +80°C (-40°F to 176°F).
• Red flashing LED backlight in case of a level alarm.
• Aluminum DIN front panel of 144 x 72mm (5.67" x 2.83") according DIN 43700 / IEC 61554.

Applications

• The D-Series is a DIN-sized display and the better alternative for your existing, not waterproof, front panel mount indicators in extreme weather outdoor applications or e.g. in food industries where working environments are often cleaned with powerful water jets.
• The D073 fits in level measurement applications where continuous level monitoring is important

• Unique, robust IP66, IP67 (NEMA4X) panel mount front enclosure made of die cast aluminum, allowing even big jets of water and total immersion.
• Programming can be done by your own crew with the exact same, plain and sensible menu-driven structure like the F-Series, saving cost and irritation. Know one, know them all!

The D077 is a versatile, panel mount level monitor with linearization and continuous level monitoring feature. In addition to the average Span, eight linearization points can be entered to compensate for the tankshape. The unit will interpolate between these points to increase the accuracy. This linearization affects all displayed information as well as the alarm output. With the level monitoring feature, one low level and one high level alarm value can be set.

Features

• Displays level, height and percentage filled.
• Eight point linearization of the tank shape - with interpolation.
• Two alarm values can be entered: low and high level alarm.
• Level: six large 17mm (0.67) digits.
• Selectable on-screen engineering units; volumetric or mass.
• Auto backup of all settings.
• Operational temperature: -40°C to +80°C (-40°F to 176°F).
• Red flashing LED backlight in case of a level alarm.
• Aluminum DIN front panel of 144 x 72mm (5.67" x 2.83") according DIN 43700 / IEC 61554.

Applications

• The D-Series is a DIN-sized display and the better alternative for your existing, not waterproof, front panel mount indicators in extreme weather outdoor applications or e.g. in food industries where working environments are often cleaned with powerful water jets.
• The D077 fits in level measurement applications where continuous level monitoring and linearization of the tankshape is important

• Unique, robust IP66, IP67 (NEMA4X) panel mount front enclosure made of die cast aluminum, allowing even big jets of water and total immersion.
• Programming can be done by your own crew with the exact same, plain and sensible menu-driven structure like the F-Series, saving cost and irritation. Know one, know them all!

The F074 is a basic level / pump controller that works with a preset value and two switch points to control a pump or valve. The low and high level switch points are entered as a percentage of the preset value to switch the device on / off. For pump control applications, the function can be inverted to empty a well. A stable level within a hysterese around the preset value is the result. The configuration of the Span, off-set and number of decimals is done through software functions, without any sensitive DIP-switches or trimmers. The display shows the actual level, preset value, high / low switch points and status.
On-screen engineering units are easily configured from a comprehensive selection.

Features

• Level control: high / low switch points and a preset value can be set.
• Displays actual level, switch points, status and preset value.
• Switch points and preset value can be set by the operator or they can be passcode protected.
• One control output for on / off pump or value control.
• Level: six large 17mm (0.67") digits.
• Selectable on-screen engineering units for level: ml, L, m³, GAL, USGAL, kg, lb, bbl or no unit.
• Selectable on-screen engineering units for height: mm, cm, m, mtr, inch, ft, mmwk, mmwc, cmwk, cmwc, mwk, mwc, inwc, ftwc, mBar, Bar, PSI or no unit.
• Green or amber LED backlight with adjustable intensity.
• Auto backup of settings in EEPROM memory.
• Easy configuration with clear alphanumerical display.
• Operational temperature: -40°C to +80°C (-40°F to 176°F).

Applications

• The F-Series is your first and best choice for field mount indicators. Especially in harsh weather conditions like rain, snow, salty atmospheres and temperatures between -40°C up to +80°C (-40°F up to 176°F) for safe and hazardous area applications!
• Basic on / off level control applications without PI(D) control requirements. Also very suitable for applications where the required level changes frequently.

• Robust IP66, IP67 (NEMA4X) field enclosure. It is so rugged, you can even stand on it!
• Intrinsically Safe available - ATEX, IECEx, FM and CSA approval for gas and dust applications.
• Programming can be done by your own crew, with the sensible menu-driven structure, saving cost and irritation. Know one, know them all!
• Very diverse mounting possibilities: walls, pipes, panels or directly onto outdoor sensors.

The D074 is a basic, panel mount level / pump controller that works with a preset value and two switch points to control a pump or valve. The low and high level switch points are entered as a percentage of the preset value to switch the device on / off. For pump control applications, the function can be inverted to empty a well. A stable level within a hysterese around the preset value is the result.

Features

• Level control: high / low switch points and a preset value can be set.
• Displays actual level, switch points, status and preset value.
• Switch points and preset value can be set by the operator or being password protected.
• Level: six large 17mm (0.67) digits.
• Selectable on-screen engineering units for level: L, m³, GAL, USGAL, kg, lb, bbl or no unit.
• Auto backup of all settings.
• Operational temperature: -40°C to +80°C (-40°F to 176°F).
• LED backlight option.
• Aluminum DIN front panel of 144 x 72mm (5.67" x 2.83") according DIN 43700 / IEC 61554.

Applications

• The D-Series is a DIN-sized display and the better alternative for your existing, not waterproof, front panel mount indicators in extreme weather outdoor applications or e.g. in food industries where working environments are often cleaned with powerful water jets.
• The D074 fits in basic on / off level control applications (e.g. for filling-up a container) without PI(D) control. Also very suitable when the required level changes frequently (e.g. for emptying a well or tank).
