The front panel has intuitive buttons and displays that make operating the batch controller clear and easy right out of the box. START, BATCH, and STOP buttons come setup by default for batch controller operation. The START button is used to begin a batching process. The BATCH button is used to quickly access the preset value. The STOP button can be pressed once to pause a batch, or twice to cancel a batch in progress. The upper and lower displays can be easily configured for your application need. The STOP button may be used to easily cycle the lower display information while the batch is stopped.

• Product Type: Digital Panel Meter
• Input: 0-20 mA, 4-20 mA; ±10 VDC (0-5, 1-5, 0-10 V); Modbus PV (slave)
• Display: Dual-line 6-digit, 0.60" (15 mm) & 0.46" (12 mm)
• Case: 1/8 DIN, High Impact Plastic
• Power: 85-265 VAC or 12/24 VDC option
• Operating Temperature: -40 to 65°C

The front panel has intuitive buttons and displays that make operating the batch controller clear and easy right out of the box. START, BATCH, and STOP buttons come setup by default for batch controller operation. The START button is used to begin a batching process. The BATCH button is used to quickly access the preset value. The STOP button can be pressed once to pause a batch, or twice to cancel a batch in progress. The upper and lower displays can be easily configured for your application need. The STOP button may be used to easily cycle the lower display information while the batch is stopped.

• Product Type: Digital Panel Meter
• Input: 0-20 mA, 4-20 mA; ±10 VDC (0-5, 1-5, 0-10 V); Modbus PV (slave)
• Display: Dual-line 6-digit, 0.60" (15 mm) & 0.46" (12 mm)
• Case: 1/8 DIN, High Impact Plastic
• Power: 85-265 VAC or 12/24 VDC option
• Operating Temperature: -40 to 65°C

The PD6310-WM is an NTEP® Certified, pulse input single or multi-stage batch controller certified as a Weighing and Measuring Device. These versatile NTEP Certified batch controllers are not only ideal for Weights and Measures batching applications, but provide reliable, cost-effective, independent batch control operation where local control is preferred to expensive systems with a much larger footprint. The PD6310-WM is a panel mount NTEP Certified batch controller with a mechanically secured, tamper-proof, programming lockout feature. This consists of a cable with a compression seal that is used to prevent access to a programming lockout jumper. Programming and operating the batch controller is via front panel start, pause, stop, and batch size buttons.

The high intensity, sunlight readable, dual line display makes it possible to locate the batch controller outdoors in direct sunlight and display a variety of useful information. For instance the upper display could show the running batch total and the lower display could show the batch size.

• Product Type: Digital Panel Meter
• Input: Pulse, open collector, NPN, PNP, TTL, switch contact, sine wave (coil), square wave, Modbus PV (slave)
• Display: Dual-line 6-digit, 0.60" (15 mm) & 0.46" (12 mm)
• Case: 1/8 DIN, High Impact Plastic
• Power: 85-265 VAC or 12/24 VDC option
• Operating Temperature: -40 to 65°C
